TERCER PUNTO MF

REFERENCIA	CATEGORIA	DIAMETRO A mm	DIMENSION ROTULA B mm	ROSCA pulgadas	DIMENSION TUBO C mm	DIMENSION D MINIMO mm	DIMENSION D MAXIMO mm	PESO Kgs	NOTA
TLMF0201	1	19.05	44	1-1/16" UNF	438	590	750	4'550
TLMF0202	1	19.05	44	1-1/16" UNF	476	610	770	5'310
TLMF0203	1	19.05	44	1-1/16" UNF	546	670	830	5'220
TLMF0204	2	25.4	51	1-1/16" UNF	546	670	830	5'400
TLMF0205	1 , 2	19.05 , 25.4	44 , 51	1-1/16" UNF	546	670	830	5'450
TLMF0206	1 , 2	19.05 , 25.5	44 , 51	1-1/16" UNF	476	610	770	5'520
TLMF0207	2	25.4	51	1-1/16" UNF	476	610	770	5'770
TLMF0208	1 , 2	19.05 , 25.5	44 , 51	1-1/16" UNF	438	590	750	5'310
TLMF0209	2	25.4	51	1-1/16" UNF	438	590	750	4'100
TLMF0210	2	25.4	51	1-1/4" UNF	527	680	870	7'990
